File:MUTI-Battery enclosure.JPG
From Fmfi
Full resolution (639 × 852 pixels, file size: 222 KB, MIME type: image/jpeg)
This waterproof enclosure holds a 12v 96aH maintenance-free battery. The battery is charged by mains power. Power goes from the battery to a Power-over-Ethernet injector, and travels up about 20m over shielded UTP cable.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 10:37, 5 July 2007 |  | 639 × 852 (222 KB) | Btucker (Talk | contribs) | (This waterproof enclosure holds a 12v 96aH maintenance-free battery. The battery is charged by mains power. Power goes from the battery to a Power-over-Ethernet injector, and travels up about 20m over shielded UTP cable.) |
